How to retrieve Image columns using Power Pages’ Portal Web API

It’s been quite a while since my last blog post. However, this topic has the potential to be so transformational, I just had to get my thoughts down.

Level
03CustomiseStage 3 of 4
Read
8 min
Includes
4 snippets · 1 figure
Written
Feb 2022

It’s been quite a while since my last blog post. However, this topic has the potential to be so transformational, I just had to get my thoughts down.

Why read on? Unlock next-level styling capabilities for your portal project 😎
Be sure to check out part 2 for how to retrieve File columns using the Portal Web API

Previously, I used the Notes table as a workaround for all my portal multimedia needs; to upload and retrieve cover artwork and sound files for tracks in my Spotify clone project, attaching due diligence and evidence documentation in my case management portals, etc.

Relatively recently, Dataverse introduced the File and Image column types. The catch was that these weren’t first class citizens of the portal and their contents couldn’t be accessed with either FetchXML or the Portal Web API. With the recent release of Read operations in the Portal Web API, all this changes 😎

Benefits of these new column types include:

How to retrieve full size images using the Portal Web API

The short version – only the answer

Like with Create, Update and Delete operations, we first need to get an authentication token before using the Portal Web API. For ease of re-use, I save this to a separate Web Template and include when required (see here for how to do so). Note – this needs to be included in every page where you make use of the API… it’s not just a matter of once per user session

Next, we need to request the image in the webapi.safeAjax function

The request type is GET (obvious I guess, as we are getting data as opposed to posting it)

The URL includes 4 key pieces of information:

Note – by default, the API will only retrieve a thumbnail-sized image – a 144px x 144px resolution square version taken from the original (and cropped if necessary) rather than the full sized image. We’ll use the size=full parameter to get around this

Retrieve a full-sized image for a single record

Retrieve a full-sized image for a single recordJavaScript
webapi.safeAjax({
    type: "GET",
    url: "/_api/musdyn_tracks({{request.params.id}})/musdyn_artwork?size=full",
    contentType:"application/json",
    success: function(res) {
    },
    error: function(xhr, status, error){
        $('body').append('<img class="img-responsive" src="/artwork-not-found.svg">');
        var errorMessage = xhr.status + ': ' + xhr.statusText;
        console.log(errorMessage);
    }
});

In this example, I’ve uploaded a fallback image to Web Files in the Portal Management app. Always good to provide graceful degradation.

The longer painful version – my journey and lessons learnt arriving at the answer

Confession – I don’t know everything!! I really struggled trying to figure this out for myself. At first I could only download the thumbnail. Then I tried adding $value?size=full at the end of the request URL to get the full sized image. Here’s what the result looked like – no idea how to work with this byte array (WTF is a byte array?!!). Besides looking a mess, it was very slow to retrieve:

Power Pages
Result of image retrieved as byte array
Fig. 01Result of image retrieved as byte array

Tip – If you can’t find help specific to the Portal Web API, it’s well worth looking to the Dataverse Web API. That’s what I did. Nishant Rana’s extremely helpful blog post on Using File and Image Data Type in Dataverse (Dynamics 365)

Nishant very helpfully points out that the image can be requested as either a byte array or in base64 format. We specify this by adding parameters to the end of the request URL like so:

Byte array:

/_api/msevtmgt_events(f7007433-a743-4054-9058-1ec4bdae10c4)/px3_heroimage/$value?size=full

Base64:

/_api/msevtmgt_events(f7007433-a743-4054-9058-1ec4bdae10c4)/px3_heroimage?size=full

Base64 is what we want. However, what the API returns is an object. The actual contents of the image are in an attribute called value:

Therefore to output the image, we use res.value:


Retrieve thumbnail images from multiple records

In my Spotify clone project, there were many cases where I needed to retrieve images from multiple records within a single web template e.g. when viewing a playlist, a list of liked tracks or a list of albums for a given artist. To achieve this, we’d amend our URL slightly. Instead of specifying a GUID, we’ll use the top parameter to specify the number records we wish to retrieve images from…

Retrieve multiple thumbnail imagesJavaScript
webapi.safeAjax({
    type: "GET",
    url: "/_api/msevtmgt_events?$select=px3_heroimage&$filter=px3_heroimage_url ne null&$orderby=px3_heroimage_timestamp desc",
    contentType:"application/json",
    success: function(res) {
        $( res.value ).each(function( index ) {
        });
    },
    error: function(xhr, status, error){
        $('body').append('<img class="img-responsive" src="/artwork-not-found.svg">');
        var errorMessage = xhr.status + ': ' + xhr.statusText;
        console.log(errorMessage);
    }
});

Note – I failed to figure out the URL format for retrieving multiple full size images 😢 but I did come up with a workaround…

Retrieve multiple full size images using topJavaScript
webapi.safeAjax({
    type: "GET",
    url: "/_api/msevtmgt_events?$select=msevtmgt_eventid&$filter=px3_heroimage_url ne null&$orderby=px3_heroimage_timestamp desc",
    contentType:"application/json",
    success: function(res) {
        $( res.value ).each(function( index ) {
                webapi.safeAjax({
                    type: "GET",
                    url: "/_api/msevtmgt_events(" + res.value[index].msevtmgt_eventid +")/px3_heroimage?size=full",
                    contentType:"application/json",
                    success: function(res) {
                    },
                    error: function(xhr, status, error){
                        $('body').append('<img class="img-responsive" src="/artwork-not-found.svg">');
                        var errorMessage = xhr.status + ': ' + xhr.statusText;
                        console.log(errorMessage);
                    }
                });
        });
    },
    error: function(xhr, status, error){
        var errorMessage = xhr.status + ': ' + xhr.statusText;
        console.log(errorMessage);
    }
});

So what are these id, timestamp and url columns?

Each image column has the following supporting fields; id, timestamp and url

The database / logical name for my image column is musdyn_artwork

The supporting columns for this are:

musdyn_artworkid The unique identifier for the image. This can be used to check whether an image has been attached before you waste time / bandwidth attempting to retrieve image data.

Example: 0638d5e5-1297-ec11-b400-000d3aca27a4

musdyn_artwork_timestamp When the image was last updated (useful for caching purposes as well as sorting).

Example: 637814835979366483

musdyn_artwork_url A download link for the image (Note – this is a Dynamics / Model-Driven App URL rather than portal URL so is no use to external users).

Example: https://yourorg.crm11.dynamics.com/Image/download.aspx?Entity=msevtmgt_event&Attribute=px3_heroimage&Id=f7007433-a743-4054-9058-1ec4bdae10c4&Timestamp=637814835979366483

In the following example, I first use the entities object to retrieve the record then check for the presence of an image using liquid. If my liquid condition returns true, only then do I retrieve the image:

Check whether Image column contains data before retrievingLiquid
{% assign track_record = entities['musdyn_track'][request.params.id] %}
{% if track_record.musdyn_artworkid %}
    <script>
        webapi.safeAjax({
            type: "GET",
            url: "/_api/musdyn_tracks({{ request.params.id }})/musdyn_artwork/?size=full",
            contentType:"application/json",
            success: function(res) {
            },
            error: function(xhr, status, error){
                $('#main').append('<img class="img-responsive" src="/artwork-not-found.svg">');
                var errorMessage = xhr.status + ': ' + xhr.statusText;
                console.log(errorMessage);
            }
        });
    </script>
{% endif %}

Further considerations

Dataverse doesn’t optimise images for the web so it’s on us to do so – whether that be manually in something like Photoshop or Gimp, or automated using Power Automate and Encodian’s excellent connector.
